CBP2-HC381 歐式接線端子台 3.81mm pitch, 10A 300VAC

CBP2-HC381 歐式接線端子台，PCB端子台 3.81mm pitch, 10A 300VAC

1. Model Number: CBP2-HC381

2. Rating: 10A 300VAC

3. Body Material: Polyamide 66, Green

4. Screw: M2, Steel, Nickel Plated

5. Wire Cage: Brass, 0.6t, Nickel Plated

6. Solder Pin: Brass, 0.5t, Tin Plated

7. Working Temperature: -40˚C to +105˚C

8. Insulation withstand Voltage: AC2000V/min

9. Insulation resistance: 500MΩ or more at DC 500V

10. Wire Range: 26~16 AWG

11. Screw Torque Value: 2kg/cm

12. Number of Poles: 2P ~ 16P

13. Pitch: 3.81mm

14. Place of Origin: Taiwan
